TIG 160/200/250/315 AC DC Inverter Mosfet Series for AC DC TIG Welder

1、Adopt advanced 100KHZ high frequency inverter technology.
2、With TIG/MMA two functions.
3、With pedal and panel control function, pedal control is optional.
4、With pre-flow and post-flow adjustment, current adjustment and clearance width adjustment.
5、Unique high frequency arc start,higher success rate of arc striking.
6、Automatic over-voltage,under-voltage,over-current protection,safe and reliable.
  • TIG 160/200/250/315 AC DC Inverter Mosfet Series for AC DC TIG Welder
  • TIG 160/200/250/315 AC DC Inverter Mosfet Series for AC DC TIG Welder
  • TIG 160/200/250/315 AC DC Inverter Mosfet Series for AC DC TIG Welder
  • TIG 160/200/250/315 AC DC Inverter Mosfet Series for AC DC TIG Welder
  • TIG 160/200/250/315 AC DC Inverter Mosfet Series for AC DC TIG Welder

SPECIFICATION

MODEL TIG160ACDC TIG200ACDC TIG250ACDC2 TIG250ACDC3 TIG315ACDC
Power Supply Voltage(V) 1P~110/220±15% 1P~220±15% 3P~380±15%
Frequency(HZ) 50/60
110 220 110 220 220 380
MMA TIG MMA TIG MMA TIG MMA TIG MMA TIG MMA TIG MMA TIG
Rated Input Power(KW) 4.5 2.7 4.9 3.0 4.5 2.7 6.6 4.1 8.4 6.3 7.9 5.9 9.8 8.4
Rated Input Current(A) 55.9 34.0 30.4 18.7 55.9 34 40.8 26 52.3 38.9 12.9 9.0 14.9 13.7
Duty Cycle(40°C 10min) 20%140A
100%108A		 20%150A
100%116A		 20%140A
100%108A		 20%190A
100%147A		 30%230A
100%178A		 30%250A
100%194A		 30%230A
100%194A		 30%250A
100%194A		 30%270A
100%209A		 30%315A
100%244A
No Load Voltage(V) 56
Welding Current Rangel(A) 10~140 10~150 10~140 10~190 10~230 10~250 10~230 10~250 10~270 10~315
Efficiency(%) ≥80 ≥85
Power Factor 0.73 0.93
Protection Class IP21
Insulation Class F
Cooling AF
Net Weight(kg) 22.3 22.8 30.5 33.7 34.5
Gross Weight(kg) 24.3 24.8 33.0 36.7 37.1
Paking Meas(mm) 640X300X565 785X310X605
Customization
The appearance, welding current, product manuals and package of our TIG welding machine can be customized according to customer requirements.

    inquiry

    Related products

    Zhejiang Linlong Welding
    Equipment Co., Ltd.

    The company is a private welding machine enterprise headquartered in Wenling City, in the southeast coastal region of Zhejiang province. We run an integrated production operation that includes TIG 160/200/250/315 AC DC Inverter Mosfet Series for AC DC TIG Welder research and development, manufacturing, sales, and service segments that function seamlessly. Our advanced production facility covers an area of around 14,000 square meters. We have been specializing in the production of welding machines and cutting machines since 1993. Our product lines include MMA welding machines, TIG welding machines, MIG welding machines, and plasma cutting machines. Our equipment is primarily applied for household DIY welding processes, hardware applications, vehicle modification, and equipment maintenance jobs. All of our products are designed and manufactured for excellent performance and durability, ensuring you can get the job done right every time.

    Certificate

    Honor

    News

    TIG 160/200/250/315 AC DC Inverter Mosfet Series for AC DC TIG Welder Industry Knowledge Expansion


    What Are the Key Features of the Mosfet TIG-315 AC DC Inverter Mosfet TIG Welder?

    The Mosfet TIG-315 AC DC Inverter Mosfet TIG Welder is a versatile welding machine known for its advanced features. It's designed for both professional welders and enthusiasts seeking high-quality TIG welding capabilities. Some key features include:

    - AC/DC Compatibility: This welder offers the flexibility to work with both alternating current (AC) and direct current (DC), making it suitable for a wide range of materials and applications.

    - Precise Welding Control: The Mosfet technology enables precise control over the welding current and voltage, allowing for accurate and clean welds, even on delicate materials.

    - Pulse Function: It comes equipped with a pulse function, which is particularly useful for welding thin materials and achieving better control over heat input.

    - Digital Display: The digital display provides real-time feedback on welding parameters, making it easier for users to set and monitor their welding settings.

    - Portable Design: Its compact and lightweight design makes it highly portable, ideal for on-site welding projects.

    - Reliable and Efficient: With Mosfet technology, it offers high reliability and efficiency, ensuring consistent and stable welding performance.


    What Makes the 160 Mosfet AC DC Inverter TIG/MMA Welder Stand Out for Welding Enthusiasts?

    The 160 Mosfet AC DC Inverter TIG/MMA Welder is a welding machine designed with welding enthusiasts in mind. Here are some standout features:

    - Dual Welding Modes: This welder offers both TIG (Tungsten Inert Gas) and MMA (Manual Metal Arc) welding modes, making it versatile for various welding tasks.

    - AC/DC Capability: Similar to the previous model, it can handle both AC and DC welding, expanding the range of materials and applications it can tackle.

    - Compact and Lightweight: Its compact size and lightweight build make it easy to transport, allowing enthusiasts to take their welding projects wherever they go.

    - User-Friendly Interface: The user-friendly interface simplifies the welding process, making it accessible to beginners while still meeting the needs of experienced welders.

    - Reliable Arc Stability: It maintains a stable welding arc, which is crucial for producing high-quality welds, especially on thin materials.

    - Affordability: This model strikes a balance between affordability and performance, making it an attractive choice for hobbyists and DIYers.


    What Sets Apart the Mosfet AC DC Inverter MMA/TIG Welder in the Welding Equipment Market?

    The Mosfet AC DC Inverter MMA/TIG Welder distinguishes itself in the welding equipment market with its unique features and capabilities:

    - Dual Welding Processes: Similar to the previous models, it offers both MMA and TIG welding processes in a single machine, providing versatility for a wide range of welding applications.

    - AC/DC Welding Flexibility: Its ability to switch between AC and DC modes enables welding on various materials, including aluminum and stainless steel.

    - Robust Construction: This welder is built to withstand demanding work environments, making it suitable for industrial applications.

    - Advanced Arc Control: It features advanced arc control technology, ensuring precise and stable arc performance.

    - Digital Control Panel: The digital control panel allows for easy adjustment of welding parameters and provides clear feedback during the welding process.

    - High Duty Cycle: With a high duty cycle, it can handle extended welding sessions without overheating, making it suitable for professional welders.
