MIG160i Inverter Igbt Series For Mig/Mag Welder

1、MMAMIG Mode.
2、2T/4T Mode.
3、With Output polarity conversion function, can weld flux core and solid wire.
4、MMA mode can be used as lift arc TIG.
5、With perfect overcurrent,overheating short voltage protection.
6、Small size,light weight and portable.
7、Single phase power supply for home use.
  • MIG160i Inverter Igbt Series For Mig/Mag Welder
  • MIG160i Inverter Igbt Series For Mig/Mag Welder
  • MIG160i Inverter Igbt Series For Mig/Mag Welder
  • MIG160i Inverter Igbt Series For Mig/Mag Welder
  • MIG160i Inverter Igbt Series For Mig/Mag Welder
  • MIG160i Inverter Igbt Series For Mig/Mag Welder

SPECIFICATION

MODEL
MIG160i
Power Supply Voltage(V)
1P~110/220±15%
Frequency(HZ)
50/60
110
220
MIG
MMA
MIG
MMA
Rated Input Power(KW)
4.1
4.6
6.0
6.1
Rated Input Current(A)
35.7
40
25.4
25.6
Duty Cycle(40°C 10min)
30%120A
30%110A
30%160A
30%140A
No Load Voltage(M)
56
Welding Current Range(A)
30~120
30~110
30~160
30~140
Welding Voltaget RangeM)
14~22
14~24
Eficiency(%)
≥80
Power Factor
0.73
Protection Class
IP21
Insulation Class
F
Cooling
AF
Wire Diameter(mm)
0.6/0.8
1.6~3.2
0.6/0.8/0.9
1.6~3.2
Net Weight(kg)
19.8
Gross Weight(kg)
22.3
Paking Meas(mm)
598X330X555
inquiry
